Technical Specs

• Number of Routes: 4 + 1 Pass Thru
• Via Pass Thru (R + L)
• Selectable Phase: 0/180 Degrees
• Variable Level: -infinite at + 6dB

• Via Low (R + L) Mono
• Subsonic Filter (Selectable): Bypass / 40/60 / 80Hz (-24dB / 8th butterworth)
• Low Pass Filter (Variable): 100Hz to 2kHz (-12dB / 8th Linkwitz-Riley)
• Bass Boost: Variable 0 to +10 dB (40Hz)
• Selectable Phase: 0/180 Degrees
• Variable Level: -infinite at + 10dB

• Via Low Mid (R + L) Mono
• High Pass Filter (Variable): 30Hz to 600Hz (-12dB / 8th Linkwitz-Riley)
• Low Pass Filter (Variable): 600Hz to 10kHz (-12dB / 8th Linkwitz-Riley)
• Selectable Phase: 0/180 Degrees
• Variable Level: -infinite at + 10dB

• Via High Mid (R and L) Stereo
• High Pass Filter (Variable): 2kHz to 10kHz (-12dB / 8th Linkwitz-Riley)
• Selectable Phase: 0/180 Degrees
• Variable Level: -infinite at + 10dB

• Input Impedance: 10K OHMS
• Output Impedance: 470 ohms
• Maximum Input Level R / L: 4.57 V RMS @ (+15.4 dBu)
• Maximum Output Level R / L: 9.3 V RMS @ (+21.6 dBu)
• Max Pass Thru R / L Output Level: 9.3 V RMS @ (+21.6 dBu)
• Frequency Response: (-1dB) from 10Hz to 100kHz
• Total Harmonic Distortion (THD): <0.01% at 1kHz
• Crosstalk (separation between channels):> ​​85dB
• Power Supply Voltage: 10.5 to 16 VDC
• Rated Power: 420mA @ 12.6Vdc
• Protection System: Polarity Inversion
• Dimensions (WxHxD): 238 x 42 x 145mm
• Weight: 0.70Kg
